Royale Limousine - Wire and Harness Location · Color · Function

Center · Divider
Plug P3
1 black ground
2 red/green oor lights
1 white/brown privacy divider
2 white/green glass divider
3 blue/brown privacy divider
4 blue/green glass divider
Plug C
Plug P
1 black ground
2 blue/yellow color wheel
3 green/orange color wheel motor
Plug N
1 black ground
2 red/black tv/vcr
NOTE: Please refer to Wire Routing Main Harness
on page 29.
