Power to Board
SOLENOID
Battery
Spare
Terminal
(+)
(-)
(+)
(-)
Positive
Engine Block
Ground at
Black, 4 Ga
by Manex Kit
Diode provided
by Manex Kit
Red, 8 Ga
Green/White
Red, 4 Ga
to Board
(Trigger Wire)
Battery Relay
Power to Board
Auxiliary Battery
Dual Alternator
Red, 4 Ga
Diode provided
16 Ga
Blue/Orange
Red, 4 Ga
ALTERNATOR
Power to Board
DUAL
TOWN CAR
FUSES
2 - 50 AMP
Diode
* TownCar: Under the hood
Location
16 Ga
POWER FUSE MODULE
PART No DESCRIPTION QTY
HC5108 1/4 - 20 x 2 Bolt 1
FEN106 1/4 x 1 1/2 Fender Washer 1
NLN109 1/4 - 20 NYLOK Lock Nut 1
LWL108 1/4 Lock Washer 1
SOLENOID
PART No DESCRIPTION QTY
HC5129 5/16 - 18 x 1/2 Bolts 2
FWL108 1/4 FLAT USS Washer 2
NLN110 5/16 - 18 NYLOK Lock Nuts 2
KN110
5/16 - 24 KEPSNUT
Solenoid Studs - Power
2
KN105
10-32 KEPSNUT
Solenoid Studs - Coil Exciter
2
F
D
C
B
A
B
C
D
12345678
8 7 6 5
4
3
2 1
E
F
E
A
ENG APPR.
CHECKED
MFG APPR.
Q.A.
UNLESS OTHERWISE SPECIFIED:
SCALE:
COMMENTS:
DWG. NO.
C
SIZE
Drawn byRevision #DescriptionsGroupsModelYearBrand
TITLE:
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
ROYALE. ANY REPRODUCTION IN PART
OR AS A WHOLE WITHOUT THE WRITTEN
PERMISSION OF ROYALE IS PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
NEXT ASSY
USED ON
APPLICATION
DIMENSIONS ARE IN INCHES
TOLERANCES:
THREE PLACE DECIMAL
FRACTIONAL
ANGULAR: MACH BEND
TWO PLACE DECIMAL
INTERPRET GEOMETRIC
TOLERANCING PER:
MATERIAL
FINISH
DM
2Alternator
110
1007
1
T-110-010-01
08/19/2008
TOWN CAR
DUAL ALTERNATOR
SCHEMATIC
SHEET 1 OF 1
