RPB Nova 3 - Breathing Air Pressure Table

13
S - SPECIAL OR CRITICAL USERS INSTRUCTIONS - SAR TABLE 1.1
This table lists air pressure ranges needed to provide the RPB
®
NOVA 3
®
with the volume of air
that falls within the required range of 6-15cfm or 170-425 lts/min according to U.S. government
regulations.
BREATHING AIR PRESSURE TABLE
1. AIR
SOURCE
2. AIR SUPPLY HOSE
3. NV2021B
BREATHING TUBE
ASSEMBLY AND
FLOW CONTROL
DEVICES
4. SUPPLY
HOSE
LENGTH
(FT)
5. MAX
NUMBER
OF
SECTIONS
6.
PRESSURE
RANGE
(PSIG AIR)
NV2016 Flow
Control Valve
Assembly
25
50
100
150
200
250
300
1
1
2
3
4
5
6
27-28
28-29
30-31
33-34
36-37
38-39
41-43
4000-01 Cold Air
Tube Assembly
25
50
100
150
200
250
300
1
1
2
3
4
5
6
55-56
56-57
60-62
65-67
70-72
77-78
80-82
4000-20 Hot Air
Tube Assembly
25
50
100
150
200
250
300
1
1
2
3
4
5
6
67-68
69-70
73-74
77-78
81-82
86-87
91-92
03-500 C40 Climate
Control Assembly
25
50
100
150
200
250
300
1
1
2
3
4
5
6
50-80
55-85
60-95
65-95
70-100
75-100
85-100
Make sure you understand the Breathing Air Pressure table before using
this respirator.
1. Use the correct air source. Do not use an ambient air pump, as it does not supply enough
pressure (column 1).
2. Conrm the part number of the air supply hose you are using (column 2) and the ow control
device (column 3) you are using.
3. Check your RPB
®
Safety Air Supply Hose is within the correct length (column 4) and the
correct number of hose sections (column 5).
4. Set the air pressure at the point of attachment within the range specied (column 6).
Make sure air is owing through your respirator when setting the air pressure.
WARNING
Portable or
Stationary
Compressor
NV2028 (25ft)
NV2029 (50ft)
NV2027 (100ft)
04-352-25-RZ (25ft)
04-352-50-RZ (50ft)
04-352-100-RZ (100ft)
