4．Input port shutdown edge latch register [5]
Each time the port changes from the on state to the off state, the driver will latch
this change edge. MODBUS address: 5
15
8
Reserve
R-0
7
6
5
4
3
2
1
0
Reserve
IN6
IN5
IN4
IN3
IN2
IN1
R-0
R-0
R-0
R-0
R-0
R-0
R-0
Table 3-7 Register details [5]
BIT
Name
Description
6～15
Reserve
Read always returns 0.
5
IN6
Input port IN6 shutdown edge latch flag
0: Input port IN6 has no shutdown edge
1: Input port IN6 has a shutdown edge
4
IN5
Input port IN5 shutdown edge latch flag
0: Input port IN5 has no shutdown edge
1: Input port IN5 has a shutdown edge
3
IN4
Input port IN4 shutdown edge latch flag
0: Input port IN4 has no shutdown edge
1: Input port IN4 has a shutdown edge
2
IN3
Input port IN3 shutdown edge latch flag
0: Input port IN3 has no shutdown edge
1: Input port IN3 has a shutdown edge
1
IN2
Input port IN2 shutdown edge latch flag
0: Input port IN2 has no shutdown edge
1: Input port IN2 has a shutdown edge
0
IN1
Input port IN1 shutdown edge latch flag
0: Input port IN1 has no shutdown edge
1: Input port IN1 has a shutdown edge
