Audio Distribution System
AD-4
22
CHAPTER 3 | INSTALLATION AND OPERATION
RS-232 PROTOCOL
All Mute Off *ZALLMUT00\r
All Mute On *ZALLMUT01\r
All Power Off *ZALLPWR00\r
All Power On *ZALLPWR01\r
All Source 1 *ZALLSRC01\r
All Source 2 *ZALLSRC02\r
All Source 3 *ZALLSRC03\r
All Source 4 *ZALLSRC04\r
Z1 Bass + *ZN01BASUP\r
Z1 Bass - *ZN01BASDN\r
Z1 Bass Flat *ZN01BAS00\r
Z1 Mute Off *ZN01MUT00\r
Z1 Mute On *ZN01MUT01\r
Z1 Mute Toggle *ZN01MUT02\r
Z1 Power Off *ZN01PWR00\r
Z1 Power On *ZN01PWR01\r
Z1 Power Toggle *ZN01PWR02\r
Z1 Source 1 *ZN01SRC01\r
Z1 Source 2 *ZN01SRC02\r
Z1 Source 3 *ZN01SRC03\r
Z1 Source 4 *ZN01SRC04\r
Z1 Status *ZN01STA00\r
Z1 Treble + *ZN01TRBUP\r
Z1 Treble - *ZN01TRBDN\r
Z1 Treble Flat *ZN01TRB00\r
Z1 Volume + *ZN01VOLUP\r
Z1 Volume - *ZN01VOLDN\r
Z2 Bass + *ZN02BASUP\r
Z2 Bass - *ZN02BASDN\r
Z2 Bass Flat *ZN02BAS00\r
Z2 Mute Off *ZN02MUT00\r
Z2 Mute On *ZN02MUT01\r
Z2 Mute Toggle *ZN02MUT02\r
Z2 Power Off *ZN02PWR00\r
Z2 Power On *ZN02PWR01\r
Z2 Power Toggle *ZN02PWR02\r
Z2 Source 1 *ZN02SRC01\r
Z2 Source 2 *ZN02SRC02\r
Z2 Source 3 *ZN02SRC03\r
Z2 Source 4 *ZN02SRC04\r
Z2 Status *ZN02STA00\r
Z2 Treble + *ZN02TRBUP\r
Z2 Treble - *ZN02TRBDN\r
Z2 Treble Flat *ZN02TRB00\r
Z2 Volume + *ZN02VOLUP\r
Z2 Volume - *ZN02VOLDN\r
Z3 Bass + *ZN03BASUP\r
Z3 Bass - *ZN03BASDN\r
Z3 Bass Flat *ZN03BAS00\r
Z3 Mute Off *ZN03MUT00\r
Z3 Mute On *ZN03MUT01\r
Z3 Mute Toggle *ZN03MUT02\r
Z3 Power Off *ZN03PWR00\r
Z3 Power On *ZN03PWR01\r
Z3 Power Toggle *ZN03PWR02\r
Z3 Source 1 *ZN03SRC01\r
Z3 Source 2 *ZN03SRC02\r
Z3 Source 3 *ZN03SRC03\r
Z3 Source 4 *ZN03SRC04\r
Z3 Status *ZN03STA00\r
Z3 Treble + *ZN03TRBUP\r
Z3 Treble - *ZN03TRBDN\r
Z3 Treble Flat *ZN03TRB00\r
Z3 Volume + *ZN03VOLUP\r
Z3 Volume - *ZN03VOLDN\r
Z4 Bass + *ZN04BASUP\r
Z4 Bass - *ZN04BASDN\r
Z4 Bass Flat *ZN04BAS00\r
Z4 Mute Off *ZN04MUT00\r
Z4 Mute On *ZN04MUT01\r
Z4 Mute Toggle *ZN04MUT02\r
Z4 Power Off *ZN04PWR00\r
Z4 Power On *ZN04PWR01\r
Z4 Power Toggle *ZN04PWR02\r
Z4 Source 1 *ZN04SRC01\r
Z4 Source 2 *ZN04SRC02\r
Z4 Source 3 *ZN04SRC03\r
Z4 Source 4 *ZN04SRC04\r
Z4 Status *ZN04STA00\r
Z4 Treble + *ZN04TRBUP\r
Z4 Treble - *ZN04TRBDN\r
Z4 Treble Flat *ZN04TRB00\r
Z4 Volume + *ZN04VOLUP\r
Z4 Volume - *ZN04VOLDN\r
Function String Function String
