It’s Under Control
®
CHAPTER 4 | SPECIFICATIONS
Power Supply 115 AC, 120W
Mounting Rack mount or free standing
Dimensions
(W x H x D)
16.9” (430mm) x 2.1” (53mm) x 13.3” (339mm)
Weight 11.0 lb. (5kg)
Warranty One Year (Parts & Labor)
All specications subject to change without notice.
GENERAL
Total Output Zones Four zones, two channels each
Audio Sources Maximum four, local and remote combined.
Audio Source Inputs
(Local)
Four, RCA jacks
Audio Source Inputs
(Remote)
Four, RJ-45 jacks
Control Input One, 3.5mm jack, compatible with industry
standard IR repeaters and receivers
Remote Source IR
Inputs
Five, 3.5mm jacks, compatible with industry
standard IR emitters
Mute Input One, 3.5mm jack
Trigger Output
(Status Jack)
One, 12VDC, 15mA max
Voltage Output One, 12VDC, 500mA max
RS-232 Ports One, Bi-directional DB-9
Phone Input
Sensitivity
AC25V-AC100V 20Hz
Doorbell Sensitivity AC/DC 3-12V
CONTROL & CONNECTIONS
