Audio Distribution System

AD-4x

CONFIGURING THE AD-4X USING THE WEB INTERFACE

The AD-4x web interface is accessible via a standard web browser (Internet

Explorer

, Firefox

, Safari

etc) on a PC, tablet or smartphone.

The web interface is used for:

• Conguring networking - IP address etc.

• Testing output zones - Each zone can have it’s current source, volume, power

and mute status adjusted during the setup process.

• Zone grouping - Output zones may be assigned to a “group”, allowing multiple

zones to be controlled simultaneously as a single output zone.

ADDING THE AD-4X TO THE ETHERNET NETWORK (LAN)

Wire the AD-4x to the Ethernet network using Cat-5 cable with the RJ45

termination and power the unit on. The network router will assign an IP address

to the Ad-4x automatically and allow it to join the network.

• The AD-4x is set to use DHCP by default.

• Router must have DHCP enabled.

ACCESSING THE WEB INTERFACE

To access the web interface, rst determine the IP address that was assigned

to the AD-4x by the network router which can be found by looking for UPNP

devices on the network.

NOTE: If using Windows XP, you may need to enable viewing of UPNP devices

and “Windows Discovery”.

• Click on My Network Places

• If UPNP devices are not displayed, under Network Tasks, click on “Show

icons for networked UPNP devices”. Click yes to allow the installation

wizard.

To view UPNP devices on the network, go to the “network” area in your version

of Windows.

• In the “Computer” tab under the Start Menu.

• Click on “Network”.

• On the right side window, scroll down to “Other Devices”.

• Find the AD-4x in the list of devices and double click on the icon to open the

web interface.

• The AD-4x icon will display the IP address it is using. Open a web browser

on your PC, tablet or smartphone and type the IP address into the browser

address bar.

Example: http://192.168.0.15

RTI AD-4x User Manual
