Audio Distribution System
AD-4x
34
CHAPTER 4 | SPECIFICATIONS
Power Supply 115 AC, 120W
Mounting Rack mount or free standing
Dimensions
(W x H x D)
16.9” (430mm) x 2.1” (53mm) x 13.3” (339mm)
Weight 11.0 lb. (5kg)
Warranty One Year (Parts & Labor)
GENERAL
Total Output Zones Four zones, two channels each (either 4 ohm or
8 ohm speakers may be connected to the zone
outputs)
Pre-Outs Four, RCA jack pairs
Audio Sources Maximum four, local and remote combined.
Audio Source Inputs
(Local)
Four, RCA jacks
Audio Source Inputs
(Remote)
Four, RJ-45 jacks
Control Input One, 3.5mm jack, compatible with industry standard
IR repeaters and receivers
Remote Source IR
Inputs
Five, 3.5mm jacks, compatible with industry
standard IR emitters
Mute Input
One, 3.5mm jack
Phone Input Sensitivity: AC25V-AC100V 20Hz
Doorbell Sensitivity: AC/DC 3-12VDC
Trigger Output (Status
Jack)
One, 12VDC, 15mA max
Voltage Output One, 12VDC, 500mA max
RS-232 Ports One, Bi-directional DB-9
Ethernet Port One, 10/100Base-T, RJ45 Connection
Unit ID Numbers 1-8, Set using 3 switches
CONTROL & CONNECTIONS
