3. Specifications
RuggedCom® RuggedSwitch™ 16 RS900G Installation Guide Rev 107
3. Specifications
3.1. Operating Environment
Parameter Range Comments
Ambient Operating Temperature -40 to 85°C
Ambient Temperature as measured
from a 30cm radius surrounding the
center of the RS900G enclosure.
Ambient Relative Humidity 5% to 95% Non-condensing
Ambient Storage Temperature -40 to 85°C
Operating Altitude 0 to 15240m (0 to 50000 ft) Over temperature range of -40 to 85°C
Table 3.1. Operating Environment
3.2. Power Supply Specifications
Power
Supply Type
Minimum Input Maximum Input Fuse Rating Isolation
Maximum Power
Consumption
12 – 24 VDC 10 VDC 36 VDC 3.15A (T)
a
1.5 kV DC
24 VDC 18 VDC 36 VDC 3.15A (T)
a
1.5 kV DC
48 VDC 36 VDC 72VDC 3.15A (T)
a
1.5 kV DC
HI (125/250 VDC)
b
HI (110/230 VAC)
b
88 VDC
85 VAC
300 VDC
265 VAC
3.15A (T)
a
4 kV AC 5.5 kV DC
10W
a
(T) denotes time-delay fuse
b
This is the same power supply for both AC and DC.
Table 3.2. RS900G Power Supply Specifications
3.3. Failsafe Relay Specifications
Parameter Value
Max Switching Voltage 30VAC, 80VDC
Rated Switching Current
0.3A @ 30VAC
1A @ 30VDC, 0.3A @ 80VDC
Table 3.3. Failsafe Relay Specifications
• Resistive Load.
• For Class-2 circuits only.
3.4. Twisted Pair Data Port Specifications
Data Port Media Distance Connector Type
10/100 Mbps Cat 5 UTP or STP 100m RJ45
Table 3.4. Twisted Pair Data Port Specifications
