1. Product Overview
RuggedCom® RuggedSwitch™ 9 RS900G Installation Guide Rev 107
1.1. RS900G Front Panel
Figure 1.1. RS900G Front Panel
LED Activity Description
Solid Link Established
LINK LED (Yellow)
Blinking Tx/Rx Activity
Power LED Solid Power On
Alarm LED Solid Alarm condition exists
Table 1.1. RS900G Front Panel LED Definitions
1.2. RS900G Bottom Panel
Figure 1.2. RS900G Bottom Panel
