Ensure that the machine is stable!
Lifting aid, load capacity: Observe the maximum filling
quantity of 220 kg per standard trolley (corresponds to
the max. filling capacity of the drum)!
Foundation load: 5,8 kN/m²!
Set up the machine on a solid level floor with sufficient
load bearing capacity!
2.2 Workplace description
The work area around the machine is at least 0.5 m on all sides; for
maintenance work it is at least 1 m; if used as passageway, it is at
least 1.2 m.
