Ruhle MPR 500 - Workplace Description

Miknetum MPR 500
9
Foundation load: 7,5 kN/m²!
Set up the machine on a solid level floor with sufficient
load bearing capacity!
2.2 Workplace description
The work area around the machine is at least 0.5 m on all sides; for
maintenance work it is at least 1 m; if used as passageway, it is at
least 1.2 m.
Swivel range of
standard trolley
support
Swivel range of
drum
