Ruijie Reyee RG-NBR-E Series Hardware Installation And Reference Guide

Hardware Installation and Reference Guide Product Overview
6
2. Specifications of Ruijie RG-NBR6215-E Enterprise-class Router
Table 1-5 Specifications of Ruijie RG-NBR6215-E Enterprise-class Router
Item
Description
Storage
DDR4 SDRAM: 2 GB
BOOTROM: 8 MB
eMMC: 8 GB
SATA: 1 TB (Optional)
I/O Setup
8 copper ports. Supports 8 10/100/1000 M (copper) fast Ethernet ports and
automatic recognition of network cables and cross-over cables.
By default, ports LAN0, LAN1, LAN2, LAN3, LAN4 and LAN5 are LAN ports,
while ports WAN0 and WAN1 are WAN ports.
Ports LAN1, LAN2, LAN3, LAN4, LAN5 and WAN1 support WAN/LAN
switchover.
1 SFP+/SFP port (SFP+ port by default). Supports XG-SFP-SR-MM850, XG-
SFP-LR-SM1310, XG-SFP-ER-SM1550 and BiDi modules. The port is a LAN
port by default and support WAN/LAN switchover. It can be also used as an
SPF port, supporting 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-
LX20/LH40-BIDI modules.
1 SPF port. Supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-
LX20/LH40-BIDI modules. The port is a WAN port by default and supports
WAN/LAN switchover.
1 management port (in bridging mode)
1 console port
2 USB ports
Hardware Disk Module
1 hardware disk module (optional)
Hot Swapping
Hot swapping of hardware disk module: not support
Interface Standard
Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX,
10GBASE-SR/LR/ZR
Console port: RS-232
Dimension (W x H x D)
440 mm x 43.6 mm x 200 mm (excluding the foot pad)
Voltage
100–240 V; 50/60 Hz
Power Consumption
Less than 25 W
Working Environment
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
