Ruijie RG-EST310 Series User Manual

Hardware Installation and Reference Guide Installing the Device
Please make full preparations as described in Chapter 2 and observe the following precautions before installing the device.
 Before connecting the power supply, please use the PoE adapter shipped with the device or use a PoE adapter with
the same specification.
 Before connecting the power cord, make sure the power switch is in the OFF position.
 Make sure the power supply is properly connected.
3.4 Installing Device
Figure 3-1 Wall Mounting
1. Secure the mounting bracket on the wall.
2. Install the device to the mounting bracket.
Figure 3-2 Pole Mounting
1. Secure the mounting bracket to the pole by threading two clamps through the mounting bracket.
