Ruijie RG-EST310 Series User Manual

Hardware Installation and Reference Guide Product Overview
1 Product Overview
RG-EST310 is an 802.11ac wireless bridge designed for video postback scenario. Its 5GHz radio delivers an access rate
of 867Mbps.
The IP68 design adapts to inclement outdoor environments such as the cold and humidity. This substantially simplifies
installation and maintenance.
1.1 Technical Specifications
Table 1-1 RG-EST310 Technical Specifications
Model
RG-EST310
Chip
QCA9886
Memory/Flash
512M bits/64M bit
RF Design
Single-Band Dual-Stream 2x2
Transmission
Protocol
802.11ac
Bands
802.11a/n/ac: 5G
(Country-Specific)
Antenna
Directional antenna, Horizontal 60°, Vertical 30°
Bridging Distance
1km
Spatial Streams
2
Max Throughput
5GHz: 867Mbps
Modulation
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
OFDM: BPSK, QPSK, 16QAM, 64QAM, 254QAM
Receive Sensitivity
11a: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps)
11n: -83dBm@MCS0, -65dBm@MCS7, -83dBm@MCS8, 65dBm@MCS15
11ac: -86dBm@MCS0, -63dBm@MCS9
Transmit Power
≤250mw (24dBm) (adjustable)
Adjustable Power
1dBm
Dimensions
(W x D x H)
147 mm ×76 mm×37 mm (without brackets, 0.48 in. x 0.25 in. x 0.12 in.)
Weight
0.35 kg
Fixed Port
One 10/100Base-T Ethernet port, supporting 24 V PoE
Button
One Reset Button
Status LED
One system status LED, one LAN status LED and three RSSI LEDs
Power Supply
24 V PoE (24 V PoE adapter) or 12 VDC
Power Consumption
< 5W
Temperature
Working Temperature:-30°C to 65°C (-22°F to 149°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity
Working Humidity: 5% to 95% (non-condensing)
Storage Humidity: 5% to 95% (non-condensing)
Mounting
Wall/pole mounting
Protection Class
IP65
