Ruijie RG-NBS3100 Series Switches Hardware Installation and Reference Guide Product Overview
7
LED
Panel Identification
State
Meaning
(0.5Hz)
Ruijie Cloud.
Blinking green
(10Hz)
The switch is being upgraded or initialized.
Solid green
The switch is connected to Ruijie Cloud.
10/100/1000Base-T
Ethernet port status
LED
1-24
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or transmitting traffic.
SFP port status LED
25-28
Off
The port is not connected.
Solid green
The port is connected at 100/1000 Mbps.
Blinking green
The port is receiving or transmitting traffic.
1.2 RG-NBS3100-24GT4SFP-P
Technical Specifications
Model
RG-NBS3100-24GT4SFP-P
CPU
Built-in CPU, single-core processor, 500MHz
Flash Memory
16 MB
SDRAM
DDRIII 256MB
Optical Module
See Appendix B.
The copper cable is not supported.
The supported module type may change at any time. Consult Ruijie Networks for the latest
information.
SFP Port
1000Base-X
100Base-X
Power Supply
 AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 6A
Input Leakage
Current
≤3.5mA
EEE
Supported
PoE
Supports PoE and PoE+.
Ports 1-24 are PoE-capable with the maximum power output of 30W per port.
The overall maximum output power of PoE/PoE+ is 370W.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Consumption
21W with no PoE load;
443W with PoE full load
Temperature
Operating temperature: 0 ºC to 50ºC
Storage temperature: -40 ºC to 70ºC
Humidity
Operating humidity: 10% to 90% RH
