Ruijie RG-NBS3200 Series

Ruijie RG-NBS3200 Series Switches Hardware Installation and Reference Guide Product Overview
11
LED
Panel Identification
State
Meaning
LED
Solid green
The port is connected.
1.3 RG-NBS3200-24GT4XS-P
Technical Specifications
Model
RG-NBS3200-24GT4XS-P
CPU
Built-in CPU, single-core processor, 800MHz
BOOTROM
N/A
Flash Memory
256 MB
SDRAM
DDRIII 512MB
Optical Module
See Appendix B.
The copper cable is not supported.
The supported module type may change at any time. Consult Ruijie Networks for the latest
information.
SFP+ Port
10GBase-R
1000Base-X
Power Supply
 AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 6A
Input Leakage
Current
≤3.5mA
EEE
Supported
PoE
Supports PoE and PoE+.
All RJ45 ports are PoE-capable with the maximum power output of 30W per port.
The overall maximum output power of PoE/PoE+ is 370W.
The available number of PDs is determined by PSE output power and PD input power in
practice.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Consumption
42W with no PoE load;
432W with PoE full load
Temperature
Operating temperature: 0 ºC to 50ºC
Storage temperature: -40 ºC to 70ºC
Humidity
Operating humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan
Supports adaptive speed adjustment
Temperature
Alarm
Not supported
EMC Standards
GB9254-2008
EN 55032:2015+AC:2016
