Ruijie RG-NBS3200 Series

Ruijie RG-NBS3200 Series Switches Hardware Installation and Reference Guide Product Overview
14
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switch is not receiving power.
Blinking green
(0.5 Hz)
The switch is running, but is not connected to
Ruijie Cloud.
Blinking green
(10Hz)
The switch is being upgraded or initialized.
Solid green
The switch is connected to Ruijie Cloud.
Port mode LED
LED Mode
Off
Indicates the switching mode.
Solid green
Indicates the PoE mode.
10/100/1000Base-T
Ethernet port status
LED
1-24
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at
10/100/1000 Mbps.
RJ45 port PoE
status LED
1-24
Off
PoE is not enabled.
Solid green
PoE is enabled. The port is operational.
Blinking green
The port has a PoE fault of overload.
SFP+ port status
LED
25F-28F
Off
The port is not connected.
Solid green
The port is connected.
Blinking green
The port is receiving or transmitting traffic.
1.4 RG-NBS3200-48GT4XS
Technical Specifications
Model
RG-NBS3200-48GT4XS
CPU
Built-in CPU, dual-core processor, 1GHz
BOOTROM
N/A
Flash Memory
256 MB
SDRAM
DDRIII 1GB
Optical Module
See Appendix B.
The copper cable is not supported.
The supported module type may change at any time. Consult Ruijie Networks for the latest
information.
SFP+ Port
10GBase-R
1000Base-X
Power Supply
 AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 2A
Input Leakage
Current
≤3.5mA
EEE
Supported
