Ruijie RG-NBS3200 Series User Manual

Ruijie RG-NBS3200 Series Switches Hardware Installation and Reference Guide Product Overview
21
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switch is not receiving power.
Blinking green
(0.5Hz)
The switch is running, but is not connected to
Ruijie Cloud.
Blinking green
(10Hz)
The switch is being upgraded or initialized.
Solid green
The switch is connected to Ruijie Cloud.
Port mode LED
LED Mode
Off
Indicates the switching mode.
Solid green
Indicates the PoE mode.
10/100/1000Base-T
Ethernet port status
LED
1-48
Off
The port is not connected.
Solid green
The port is connected at 10/100/1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at
10/100/1000 Mbps.
RJ45 port PoE
status LED
1-48
Off
PoE is not enabled.
Solid green
PoE is enabled. The port is operational.
Blinking green
The port has a PoE fault of overload.
SFP+ port status
LED
49F-52F
Off
The port is not connected.
Solid green
The port is connected.
Blinking green
The port is receiving or transmitting traffic.
