Ruijie RG-S5310-E Series User Manual

Hardware Installation and Reference Guide Product Overview
35
 SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
 See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks for
details.
Power Supply Module
Slots
2
Power Supply Module
 RG-PA600I-P-F
AC Input
Rated Voltage Range: 200 V AC to 240 V AC
Maximum Voltage Range: 176 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 8 A
 RG-PD600I-P-F
DC Input
Rated Voltage Range: -48 V DC to -60 V DC
Maximum Voltage Range: -38 V DC to -75 V DC
Rated Current Per Circuit: 20 A
 RG-PA1000I-P-F
AC Input
Rated Voltage Range: 200 V AC to 240 V AC
Maximum Voltage Range: 176 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 8 A
SFP+ Port
10GBase-R Capable
1000Base-X Capable
RTC
Supported
PoE
All RJ45 ports are PoE+ capable and each port provides up to 30 W of power.
The PoE+ port is compliant with both the PoE (IEEE802.3af) and PoE+ (IEEE802.3at) standards.
The maximum number of PoE devices supported by the switch is determined by the available
PoE consumption of the switch and the actual PoE consumption of each device.
The PoE port is compliant with Alternative A.
Power Consumption
Without PoE Load: < 75 W
With PoE Full Load: < 1570 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
