WINCH PARTS NUMBERS RUNVA 11XP
No. Part # Qty Description Remark
1 X1100001 3 Terminal Protect
2 X1100100-S
1 Motor Assembly
3 X1100002 6 Cap Screw M10 x 35
4 X1100003 6 Lock Washer Φ10
5 X1100004 6 Think Flat Washer Φ10
6 X1100005 4 Hex Nut M10
7 X1100200 1 Break / Shaft Assembly
8 X1100006 2
Bushing—Drum
9 X1100007 2 Tie Bar
10 X1100008 2 Ring Seals
11 X1100009 1 Cap Screw M6 x 10
12 X1100010 4 Lock Washer Φ8
13 X1100011 4 Cap Screw M8 x 30
14 X1100300 1 Drum Assembly
15 X1100012 10 Screw M4 x 25
16 X1100013 10 Lock Washer Φ4
17 X1100014 1 End Bearing
18 X1100015 1 Gasket
19 X1100016 1
Gear—Ring
20 X1100400 1
Gear Carrier Assembly（Output）
21 X1100500 1 Gear Carrier Assembly（Intermediate）
22 X1100600 1 Gear Carrier Assembly（Input）
23 X1100017 1 Gear—Input Sun
24 X1100018 1 Trust Washer
25 X1100019 1
Gear—Housing
26 X1100020 1 Clutch Screw
27 X1100021 1 Ring Seals
28 X1100022 1 Clutch Cover
29 X1100023 1 Clutch Handle
30 X1100024 2 Locknut M10
31 X1100700 1 Roller Fairlead
33 X1100800-S
1 Control Box
34 X1100900 1 Remote Control Switch（RC3）
35 X1101000 1 Cable Assembly
36 X1100029 1 Strap
37 X1100027 2 Flat Head Screw M5 x 6
38 X1100026 1 Control Box Fixing Panel
39 X1100030 4 Hex Head Screw M8 x15
40 X1100031 1 Control Box Soleplate
41 X1100032 2 Plug Screw M5 x 8
42 X1100033 2 Soleplate Bracket
43 X1100034 4 Locknut M8
To Next Page
