9
SPECIFICATION
Rated line pull
110000 lbs (4990 kgs)
Motor: series wound
12V:Input: 4.9kW /6.5hp
Gear reduction ratio
230:1
Cable (Dia.× L) Ø3/8"×85 ' (Ø9.2mm×26m)
Drum size (Dia.× L)
Ø2.48 "×8.8 " (Ø63mm×223 mm)
Mounting bolt pattern
10 "×4.5 " (254mm×114.3 mm) 4-M10
Overall dimensions
(L×W×H)
21.3"×6.3"×10.7"
540mm ×160 mm ×272 mm
Pull, Speed, Amperes, Volts (First layer):
Line Pull Line Speed ft/min (m/min) Current A
Ibs (kgs) 12V DC 24V DC 12V DC 24V DC
0(0) 22.3(6.8) / 100 /
4000(1814)
13.1(4.0) / 220 /
8000(3629)
9.8(3.0) / 330 /
11000(4990)
5.8(1.8) / 540 /
Line Pull And Rope Capacity In Layer
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 11000(4990) 16.1 (4.9)
2 8766(3976) 36.4 (11.1)
3 7286(3305) 60.0(18.3)
4 6233(2827) 83.7(25.5)
