MODEL F73（17603）
15
Fast Rinse
Time
10min.
0～99∶ 59
Fast rinse time (Minute)
Backwash
Time
10min.
0～99∶ 59
Backwash time (Minute)
Brine &
Slow
Rinse
Time
60min.
0～99∶ 59
Brine &Slow rinse time (Minute)
Brine Refill
Time
5min.
0～99∶ 59
Brine refill time (Minute)
Maximum
Interval
Regenerat
ion Days
H-30
30
0～40
Regenerate on the day even through
the available volume of treated water
do not drop to zero (0).
Output
Control
Mode
b-01
01
01or 02
Mode 01: Signal turn on start of
regeneration and shut off end of
regeneration. (Connection refer to
the Figure P4)
Mode 02: Signal available only
intervals of regeneration cycles and
in service. (Connection refer to the
Figure P4)
B. Process Display
