Russell Hobbs RHCC5001

6
CARPET WASHER
FEATURE DIAGRAM
1. Handle
10. Dirty water tank
2. Carry Handle
11. Brush
bar (not visible)
3.
On/Off Switch
12. Clean water release trigger
4.
Clean water tank cap
13.
Power cord tidy
5. Clean water tank release handle
14. Upper
power cord holder
6. Clean water tank
15. Power cord
7. Dirty
water tank locking latch
16. Lower power cord holder
8.
Dirty water tank release handle
17. Handle release pedal
9. Dirty
water tank filter
