Russell Hobbs RHTTDW6W User Manual

When to Refill the Rinse Aid Dispenser
There is a rinse aid warning indicator light in the control panel which will light when there is no
or little rinse aid in the rinse aid dispenser. Alternatively you can manually check/estimate the
amount of rinse aid in the rinse aid dispenser from the colour of the optical level indicator
located next to the cap. When the rinse-aid container is full, the whole indicator will be darker.
As the rinse-aid diminishes, the size of the dark dot decreases. You should never let the rinse
aid level fall 1/4 full.
As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator changes, as
illustrated below:
1. To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
2. Pour the rinse aid into the dispenser, being careful not to overfill.
3. Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right)
arrow.
NOTE: Clean up any rinse aid spilled during filling with an absorbent cloth to avoid excessive
foaming during the next wash. Don't forget to replace the cap before you close dishwasher
door.
15
Rinse Aid indicator
1
2 3
Rinse Aid
dispenser cover

Russell Hobbs RHTTDW6W Specifications

General

Door color	White
Control type	Buttons
Product size	Compact
Built-in display	Yes
Custom panel-ready	-
Appliance placement	Freestanding
Cycle time	230 min
Noise level	49 dB
Delay start (max)	24 h
Dishwashing programs	Eco, Glass/delicate, Intensive, Quick, Universal
Number of place settings	6 place settings
Number of washing programs	6
Maximum water flow pressure	1000 kPa
Minimum water flow pressure	40 kPa
Cycle time (quick washing program)	30 min
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Water consumption per cycle	6.5 L
Energy consumption per cycle	0.613 kWh

Weight and Dimensions

Depth	500 mm
Width	550 mm
Height	438 mm
