Russell Hobbs RHTTDW6W User Manual

Connection of the Water Supply & Drain Hose
• Ensure the drain hose is securely attached, to prevent it coming away while the machine is
in use and causing a flood.
• Fit the end drain hose that is connected to the waste pipe securely by using a “Jubilee”
type clip.
• If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained
directly into the sink. It will be necessary to drain excess water from hoses into a bowl or
suitable container that is held outside and lower than the sink.
• The water drain hose must be less than 600 mm from the bottom of the appliance to
prevent problems during the draining phases.
• Remove the sink plug when the appliance drains water to prevent that the water goes back
into the appliance.
• If you connect the water drain hose to a trap spigot under the sink, remove the plastic
membrane (A). If you do not remove the membrane, remaining food can cause a blockage
in the drain hose spigot.
31
A

Russell Hobbs RHTTDW6W Specifications

General

Door color	White
Control type	Buttons
Product size	Compact
Built-in display	Yes
Custom panel-ready	-
Appliance placement	Freestanding
Cycle time	230 min
Noise level	49 dB
Delay start (max)	24 h
Dishwashing programs	Eco, Glass/delicate, Intensive, Quick, Universal
Number of place settings	6 place settings
Number of washing programs	6
Maximum water flow pressure	1000 kPa
Minimum water flow pressure	40 kPa
Cycle time (quick washing program)	30 min
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Water consumption per cycle	6.5 L
Energy consumption per cycle	0.613 kWh

Weight and Dimensions

Depth	500 mm
Width	550 mm
Height	438 mm
