9.3. LUBRICANT AND HYDRAULIC OIL TABLE
Group
Lubricant/Hydraulic oil
Symbol
Joints
MOBILBREASE MP
Extractable elements
ESSO BEACON EP2
Oil tank
ESSO INVAROL EP68 oppure AGIP ATF D
Reduction gear
ESSO GLYCOLUBE
9.4. LUBRICATION OF THE ECTRACTABLE ELEMENTS
• To lubricate the extractable parts of the boom, you have to extend the boom to its max extension
and grease all sides by means of a brush; besides it is necessary to grease the traction chain too.
• To lubricate the extractable parts of the stabilizers, you have to extend the cross-member of front
stabilizers to their max extension and grease all sides by means of a brush.
• To lubricate the fifth wheel, grease by means of a grease pump.
!
WARNING
DANGER
Lubricate only when the engine is off, to avoid any squashing of your limbs.
!
WARNING
WARNING
Use oils and greases indicated in the table.
9.5. LUBRICATION PLAN
After having done a general cleaning of the machine, it is necessary to grease in the junction points where
there is lubricator with red cup by means of a grease pump every 300 hours.
!
WARNING
DANGER
Lubricate only when the engine is off, to avoid any squashing of your limbs.
!
WARNING
WARNING
Use oils and greases indicated in the table.
9.6. MACHINE CLEANING
Before any lubrications and greasing, it is necessary to do a general cleaning of the machine. The operators
must wear their protective garments.
!
WARNING
DANGER
Do not clean the machine when it is connected to the supply mains (220 volt)
!
WARNING
WARNING
Do not turn the jet of water towards the controls and the electrical components, in order to
avoid any damages.
WARNING
Use only authorized - inflammable – no-toxic solvents.
