6 Operation
6-18
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
6.5.3.3 Jacking on both sides within vehicle profile
The jacking on both sides within vehicle profile is carried out by means of
the push button „Minimum jacking“ together with one of the three push but-
tons for jacks „Left within profile“, „Right within profile“ or „Full jacking“.
Component
Movement /
Indication
Execution at operating panel
Jacks rear
vertically
extension
Actuate push button „Minimum jack-
ing“ (keep depressed).
The computer control system stops the movement automatically when:
 the rear stabilising jacks have contact with the ground.
or (according to adjustment)
Jacks left and
Jacks right
vertically
extension
Actuate push button „Minimum jack-
ing“ (keep depressed).
The computer control system stops the movement automatically when:
 all the four stabilising jacks have contact with the ground.
afterwards
Jacks left and
Jacks right
vertically
extension
Actuate one of the three push buttons
for jacks (keep depressed).
The computer control system stops the movement automatically when:
 all the stabilising jacks have contact with the ground,
 the wheels of the vehicle are unloaded, i.e. lifted off the ground
 and the electronically measured inclination of the Steiger is within the
permissible positioning inclination.
The inclination of the Steiger must at all events be controlled by means of the
levelling indicator!
Pilot lamps
„Jack front left“,
„Jack rear left“,
„Jack front right“,
„Jack rear right“
shines
Pilot lamp, red
„Basic position“
shines
