4 Operating elements and displays
4.1 Arrangement of Emergency Cut-off Push buttons
The Ruthmann-Steiger is equipped with the following Emergency Cut-off
push buttons:
1. At the switch box on working
cage.
1. In the switch box at Steiger-
substructure on the right side
in travelling direction, above
touch panel of emergency
control.
