2 Technical Specifications
BA.GB.12-27409-05-07-FTA-jr
2.3 Working ranges
The working ranges are based et al. on the following jacking-variants:
(The permissible inclination of positioning must not be exceeded.)
1. Fully jacking
All jack arms are completely extended horizontally.
All jacks have ground contact.
The vehicle wheels have ground clearance.
2. Left-hand side jacking within vehicle profile
The jack arms remain on the left-hand side horizontally com-
pletely in their retracted position. They are extended horizontal-
ly completely on the opposite side.
All jacks have ground contact.
The vehicle wheels have ground clearance.
3. Right-hand side jacking within vehicle profile
The jack arms remain on the right-hand side horizontally com-
pletely in their retracted position. They are extended horizontal-
ly completely on the opposite side.
All jacks have ground contact.
The vehicle wheels have ground clearance.
4. Jacking within the vehicle profile on both sides
The jack arms remain completely retracted on both sides in
horizontal position.
All jacks have ground contact.
The vehicle wheels have ground clearance.
5. Minimum jacking
The jack arms remain completely retracted on both sides in
horizontal position.
The rear jacks have ground contact – the position of the front
jacks is variable.
The vehicle wheels have ground contact.
The working range „Fully jacking“ is shown below. The further working
ranges may be gathered from the annex.
