6 Operation
BA.GB.12-27409-05-07-FTA-jr
RUTHMANN-Steiger
®
TB270
6-33
6.6.2 Movement of jacks
Remarks, instructions and pre-conditions of chapter „Operating the Steiger“
must be observed.
Full jacking
Component
Movement /
Indication
Execution
Jacks left and
Jacks right
completely
horizontally
extension
Depress push button „Full jacking“
(keep depressed).
Jacks left and
Jacks right
afterwards
vertically
extension
The computer control system stops the movement automatically when:
 all the stabilising jacks have contact with the ground,
 the wheels of the vehicle are unloaded, i.e. lifted off the ground
 and the electronically measured inclination of the Steiger is within the
permissible positioning inclination.
The inclination of the Steiger must at all events be controlled by means of the
levelling indicator!
Unilateral jacking within vehicle profile
Component
Movement /
Indication
Execution
Jacks left
completely
horizontally
extension
Depress push button „Right within
profile“ (keep depressed).
or
Jacks right
completely
horizontally
extension
Depress push button „Left within pro-
file“ (keep depressed).
Jacks left and
Jacks right
afterwards
vertically
extension
