6 Operation
BA.GB.12-27409-05-07-FTA-jr
RUTHMANN-Steiger
®
TB270
6-35
Minimum jacking
Component
Movement /
Indication
Execution
Jacks rear
vertically
extension
Depress push button „Minimum jack-
ing“ (keep depressed).
The computer control system stops the movement automatically when:
 the rear stabilising jacks have contact with the ground.
The inclination of the Steiger must at all events be controlled by means of the
levelling indicator!
or (according to adjustment)
Jacks left and
Jacks right
vertically
extension
Depress push button „Minimum jack-
ing“ (keep depressed).
The computer control system stops the movement automatically when:
 all the four stabilising jacks have contact with the ground.
The inclination of the Steiger must at all events be controlled by means of the
levelling indicator!
Retraction of jacks
Component
Movement /
Indication
Execution
Jacks left and
Jacks right
vertically
retraction
Depress push button „Jacks up“ (keep
depressed).
Vehicle wheels
Contact with the
ground
Jacks left and
Jacks right
afterwards
horizontally
retraction
