RUTHMANN Steiger TB270 - Page 210

9 Maintenance
9-24
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
Example )*
Limit switches
Press pin switch
Approach switches
Mercury ring
switch
Angle sensor
Inclination
sensor
Cable length
transducer
Pressure trans-
former
Inclination sensor
)* The illustrated sensors are elementary representations. The sensor
technology of the Ruthmann-Steiger itself can differ from it in form and
type.
