3 Description of the
Ruthmann-Steiger
BA.GB.12-27409-05-07-FTA-jr
3.4 Fuses
The power circuits and its consumers are secured with electrical fuses.
3.4.1 Fuses carrier chassis
Indications concerning the electrical fuse protection of the carrier chassis
are to be taken from the operating instructions of the chassis manufacturer.
3.4.2 Fuses Ruthmann-Steiger
Fuses next to vehicle battery
F10 25 A Power supply battery
F11 20 A Power supply battery
Fuses inside driver’s cab (depend on the carrier-chassis)
F102 3 A Connection power supply over ignition
Printed circuit board for fuses in switch box (emergency control) at
Steiger-substructure. A printed circuit board with fuses is mounted at the
interior side of the rotatable frame. The fuses are accessible from out-
side.
F1 7,5 A Flashing beacon / rotating flashing beacon turret left
F2 7,5 A Flashing beacon / rotating flashing beacon turret right
F3 10 A Heating element control panel of cage, searchlight
cage, flashing beacon / rotating flashing beacon cage
F4 Free
F5 3 A Pilot lamps driver’s cab, ignition
F6 Free
F7 5 A Blinker lamps on jacks
F8 Free
F9 Free
F10 3 A Limit switches, approach switches, push buttons for
commands
F11 3 A Power unit computer control, CAN-module, joystick
pilot lamps cage
