4 Operating elements and
displays
BA.GB.12-27409-05-07-FTA-jr
RUTHMANN-Steiger
®
TB270
4-13
Plain text indication
Meaning
x %TEL Time %LML
FLdn RLdn FRdn RRdn
x
%TEL
Time
%LML
FLdn
RLdn
FRdn
RRdn
 Display page
 Value of telescopic extension in per-
cent (100% = max. telescopic exten-
sion allowed)
 Time of internal clock of computer
control
 Value of load moment in percent,
100% = LML-cut-off
 Jack front left ground contact
 Jack rear left ground contact
 Jack front right ground contact
 Jack rear right ground contact
x WHcm WWcm 0.1AB
TCdeg RAdeg Tcylcm
x
WH
WW
0.1AB
TCdeg
RAdeg
Tcylcm
 Display page
 Working height in cm (approx. plat-
form height + 2 m)
 Working distance in cm (approx. dis-
tance from the centre of the turret to
the rear edge of the working cage + 50
cm)
 Angle of elevation of boom in 1/10
degrees
 Rotation angle of boom in degrees
(teeth counter)
 Rotation angle of boom in degrees
(potentiometer)
 Telescope cylinder extension in cm
x FAdn NoGear
FLoutRLoutFRoutRRout
x
FAdn
NoGear
FLout
RLout
FRout
RRout
 Display page
 Front tyres ground contact (Front axle
down) (optional extra)
 „1“, if no gear is shifted
 Jack front left horizontally extended
 Jack rear left horizontally extended
 Jack front right horizontally extended
 Jack rear right horizontally extended
