4 Operating elements and
displays
4-16
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
Plain text indication
Meaning
Fault memory
deleted on
 Indication of last deletion of fault memory
„day.month hour:minute year“.
Numerical values
 Numerical values for the Ruthmann-after-sales-
service.
Button depressed on
E-control right side
or
Button depressed on
E-control left side
or
Button depressed on
remote control
or
Button depressed on
work. cage control
 Indication of depressed buttons according to the
pick-up matrix.
Example:
Button depressed on
5
E-control right side
The first button on the second line of the emer-
gency control (placed on the right side of the
vehicle) is depressed. No page number is indi-
cated.
Volt HP KP
 Voltage in Volt. The values are displayed for the
central processing unit (CPU) and for the control
processor (CP).
Software-Version
 Software version of Ruthmann-Steiger.
Change-over language
Change=sp.funct
 Language administration.
Password required
Cont.=special funct.
or
Password already
typed in
 The following pages can only be read after input
of password.
This page is not
used
 Blank page inserted. Use the „Display up“ or
„Display down“ function keys to scroll further.
3 movements at the
same Change=sp.funct
or
2 movements at the
same Change=sp.funct
 Okay for possibility, that a number of up to three
Steiger movements are possible simultaneously.
Sens.cont. from cage
possible Change=Sp.f
or
Sens.cont. from cage
no pos Change=Sp.f
 Okay for possibility to switch on or switch off the
sensitive control through the push button „Spe-
cial function“ on the control board in working
cage.
2 jacks at minimal
jacking chan=sp.func
 Jacking variant for minimum jacking. Either only
the rear jacks or all 4 jacks are extended verti-
