ryan 544951J - Product Specifications; Model Specifications; Technical Data and Dimensions

26
Jr.
Sodcutter
SPECIFICATIONS
Models: 544951J......Jr. Sodcutter - 12 in.(30.5cm)
544952J......Jr. Sodcutter - 18 in.(45.7cm)
Engine
Model.............4 cycle 6.5H.P.(4.8KW) B&S Vanguard,
Model 124352, Type 0135,
Trim F1, 12.4 cu. in. (203 cc)
Starter...................................................... Recoil
Governor.......... 3600 RPM + 100 RPM, no load
Clutch............... spring loaded belt tightener type
Reduction
Engine to blade....................................... 2.94:1
Engine to drive wheels............................ 55.8:1
Models: 544953C.....Jr. Sodcutter - 12 in.(30.5cm)
544954C.....Jr. Sodcutter - 18 in.(45.7cm)
Engine
Model................ 4 cycle 5.5 H.P. Honda
Model GX160-K1QX2, GX160 OHV
9.9 cu. in. (163 cc)
Starter...................................................... Recoil
Governor.......... 3600 RPM + 100 RPM, no load
Clutch............... spring loaded belt tightener type
Reduction
Engine to blade....................................... 2.94:1
Engine to drive wheels............................ 55.8:1
Wheels:
Drive................. 8" (203 mm) Dia. w/knobby
tread vulcanized to hub
Rear.............8 x 1.75 (203 X 45mm) semi-pneumatic
tires
with pre-packed ball bearings
Drive:
Engine to gear case................. "A" section belt
Gear case to drive shaft
and blade drive...........................................roller chain
Gear case:
Lubrication.................................. EP140 Gear lube
Capacity...................................... 3 1/2 Pints (1.7L)
Cutting width:
544951H & 544953C..................11 3/4" (298 mm)
544952H & 544954C........................18" (457 mm)
Blade pitch:
Hand lever adjustment............... variable 0
O
to 9
O
Blade speed: .....
1225 oscillations/min @ 3600 engine RPM
Dimensions:
Width.......................................... 24" (600 mm)
Length........................................ 49" (1244 mm)
Height......................................... 33" (838 mm)
Wheelbase................................. 19" (483 mm)
Weight:
544951H & 544953C................ 333 lbs. (151 Kg)
544952H & 544954C................ 377 lbs. (171 Kg)
TOUCH -UP PAINT:
16OZ. (0.5L) Spray can, order P/N 65334
