33
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
JR SOD CUTTER
FIGURE 3
SIDE ARMS, PITMAN ARMS AND HANDLES
1 64123-50 BOLT-HEX 3/8-16X1 2
2 64123-107 BOLT-HEX 5/16-18X7/8 4
3 64123-61 BLT-HEX 5/16-18X1-3/4 2
4 328018 SCRW,.44-14 1.12 YS HX 6
5 515011 SCRW,.31-24 1.00 ZS HX 6
6 515729 BUSHING 2
7 516067 BUSH,STL.515X.874X1.015 2
8 4135868-02 COVER,HANDLE YELLOW 1
9 521435.7 SHAFT, LOWER 1
10 4164446 PLATE-ADJUSTMENT STOP 1
11 4114727 KNOB-SPEED CONTROL 1
12 4175983 LABEL-CUT DEPTH, JR SOD 1
13 4164384.2 BRACKET, PIVOT 2
14 4164681 S-ECCENTRIC ASSY 2
(INCLUDES ITEMS 15 & 16)
15 521424 RING 1
16 548814 RACE, INNER 1
17 545437 ARM AY 2
(INCLUDES ITEMS 18-22)
18 64197-025 BLT-TDFM 1/4-20X5/8 2
19 521425.2 PLATE - COVER 1
20 521427 ARM, PITMAN 1
21 521428 BRG,NDL 1.25 1.62 1.06 1
22 85010-03 FITTING (KC) 2
23 545443.7 BRACKET AY 2
(INCLUDES ITEMS 24, 25
24 521429 BRONZE BEARING 1
25 85010N ZERK-GREASE 1
26 4176189 ARM AY, SIDE 2
(INCLUDES ITEMS 27-31, 49)
27 521436 BALL BEARING 1
28 521438 GREASE SEAL 1
29 548138 BRG,NDL.88 1.12 1.00 2
30 64144-42 RING-RET 1.125 INT INV 2
31 85010N ZERK-1/4 28 STR. SFTH 4
32 4164541.7 WLDMT-LEVER 1
33 4176171 S-H-FRAME W/DECAL 1
(INCLUDES ITEM 55)
34 545449.7 HANDLE AY 1
35 524549 ROD,TIE LOWER 1
36 524550 ROD,TIE UPPER 1
37 64268-05 NUT FL NYLCK 1/2-13 2
38 64025-03 NUT-HEX 5/16-24 6
39 64006-16 LOCKWSHR-5/16 HI-COLLAR 2
40 64151-33 NUT-HEX 1/2-20 TOP LCK JAM 2
41 800513 SCRW-SCKT 5/16-18-1-1/4 2
42 548056 NUT,.44-14 YS HX UNITORQ 6
43 64268-02 NUT-FL NYLN LCK 5/16-18 2
44 64268-03 NUT-FL NYLN LCK 3/8-16 5
45 64163-99 WSHR-.510X1.31X.179 5
46 64006-02 LOCKWSHR-HELICAL 5/16 6
47 4113281 WASHER, SPCL .531 SQ 2
48 4178003-12.7 BLADE-SOD CUTTER, 12" 1
4178003-18.7 BLADE-SOD CUTTER 18"
4178003-18LC.7 LASER CLAD 18" BLADE
49 4164033 LABEL-CHF VERT 2
50 2308066 WASHER-FIBER 1
51 64163-31 WSHR-15-64X1X12GA 1
52 64018-7 BLT-CRG 3/8-16X1/1/4 1
53 64268-03 NUT-FL NYLON 3/8-16 1
54 4164570.7 WLDMT-HANDLE 1
55 4175983 LABEL-CUT DEPTH 1
56 64141-6 NUT-WLF 5/16-18 4
57 4135868-01 COVER,HANDLE GREEN 1
58 4135868 COVER,HANDLE BLACK 1
