ryan 554910A - Specifications

16
Lawnaire
IV & V
with EST
SPECIFICATIONS
LAWNAIRE IV
Dimensions:
Width.......................................... 28" (711 mm)
Length......................................... 51" (1295 mm)
Length (handle folded)............... 46" (1168 mm)
Height (transport)....................... 47.5" (1206 mm)
Height (handle folded)................ 30" (762 mm)
Net Weight:
Dry, w/o acc. weight................... 240 lbs. (109 Kg)
Dry, w/ acc. weight..................... 279 lbs. (126 Kg)
With water tank full
and acc. weight.......................... 280 lbs. (127 Kg)
Speed:
Transport.......... 3.6 mph (5.8 kph.)
Aerate................. up to 3.5 mph (5.6 kph)
Drive:
Primary....................................... V Belt, 4L section
Secondary..................... #40 plated roller chain
Wheels:
Front................. 11" (279 mm) Dia. water tank
5.2 gal. (19.7 L) max. capacity
Rear.................. 8 x 2.50 semi-pneumatic tires
with 3/4" ball bearings
Aeration:
Tines.... 3/4" (19 mm) formed from .08" hardened
chrome molybdenum alloy steel, 30 per unit
Penetration Depth..................... 2 3/4" (70 mm) max.
Swath Width.............................. 19" (483 mm)
Hole Pattern..... 3 3/4" x 7" (95 x 178 mm) on center
Production..................... Up to 28,975 sq. ft. / hour
. .................... Up to 2692 m² / hour
LAWNAIRE V
Dimensions:
Width.......................................... 35.5" (902 mm)
Length......................................... 52.5" (1334 mm)
Length (handle folded)............... 46" (1168 mm)
Height (transport)....................... 47.5" (1206 mm)
Height (handle folded)................ 30" (762 mm)
Net Weight:
Dry, w/o acc. weight................... 228 lbs. (122 Kg)
Dry, w/ acc. weight..................... 266 lbs. (140 Kg)
With water tank full
and acc. weight.......................... 330 lbs. (1497 Kg)
Speed:
Transport.......... 3.6 mph (5.8 kph.)
Aerate................. up to 3.5 mph (5.6 kph)
Drive:
Primary....................................... V Belt, 4L section
Secondary..................... #40 plated roller chain
Wheels:
Front................. 11" (279 mm) Dia. water tank
7.9 gal. (29.9 L) max. capacity
Rear.................. 8 x 2.50 semi-pneumatic tires
with 3/4" ball bearings
Aeration:
Tines.... 3/4" (19 mm) formed from .08" hardened
chrome molybdenum alloy steel, 42 per unit
Penetration Depth..................... 2 3/4" (70 mm) max.
Swath Width.............................. 26 1/2" (673 mm)
Hole Pattern..... 3 3/4" x 7" (95 x 178 mm) on center
Production..................... Up to 40,400 sq. ft. / hour
. .................... Up to 3753 m² / hour
Engines:
Model 554910A & 544913A
Model......................................HONDA GX120K1HX 4 cycle.... 7.2 cu.in. (118 cc)........*3.5 HP (2.6 KW)
Starter.........................................Recoil, on/off switch
Governor....................................3200 RPM, no load
Idle Speed..................................1400 + 100 RPM
Fuel Tank.................................. 3.4 qt. (3.2 L)
Gear Reduction.......................................6 to 1
Model 544914B & 544916B
Model................#12S4520131F8, Type 0141, Trim .01 Briggs& Stratton 4 cycle...12.5 cu.in. (206cc)..*6.0HP
(4.5KW)Starter.........................................Recoil, on/off switch
Governor.......... .......3200 RPM +/- 100 RPM, no load
Idle Speed...............................................2000 RPM
Fuel Tank................................................3.2 qt. (3.0 L)
Gear Reduction.......................................6 to 1
* as tested by manufacturer @ 3600 R.P.M.
