10
Lawnaire
IV & V
with EST
CONTROLS
HANDLE CONTROLS
Transport Lift Handle C - Pushing down on the
handle lowers the tines for aerating. Pulling the
handle up raises the tines so the aerator can be
moved or transported without incurring damage to
the unit or the turf.
Clutch Control Handle (Bail) B - Engages aerator
drive clutch. Pull on the handle to engage the clutch.
Release the handle to disengage.
Releasing the clutch on an incline will allow the unit
to roll down the incline.
Throttle Control A - The throttle control, located
on the handle, adjusts the engine speed. Pushing
the control forward increases the speed; pulling the
control back reduces the speed.
Honda Engine Controls
The engine is equipped with a choke A, a fuel valve
B and an On/Off switch C . The fuel valve and the
On/Off switch must both be in the "ON" position to
start the engine. Turn the On/Off switch to "OFF" to
stop the engine. Using the choke will help start a
cold engine. After the engine starts, adjust the choke
for best running results. Once the engine warms, the
choke should not be needed.
Briggs & Stratton Engine Controls
The engine is equipped with an On/Off control A, a
choke control B and fuel shut-off valve C. The fuel
valve and On/Off control must both be in the "ON"
position for the engine to be started. Turning the
On/Off control to the "OFF" position will stop the
engine. Using the choke control will help start a cold
engine. After the engine starts, adjust the choke for
best running results. Once the engine warms up, the
choke should not be needed.
