19
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
Lawnaire
IV & V
with EST
FIGURE 1
FRAME GROUP
1 64140-9 COTTER PIN, 12 x 1.12 YS 3
2 64262-018 BLT-FLG HD 3/8-16X1-3/4 1
3 4137227 SPRING-TORSION 1
4 64163-61 WASHER 2
5 841261 SPROCKET, 16T, 1/2P 1
6 2703341.7 BELLCRANK AY, IDLER 1
7 2703519 BUSHING, SH .33X.75X.88 2
8 2703756.7 LINK AY, LOWER LEFT 1
9 2703757.7 LINK AY, UPPER LEFT 1
10 2703758.7 LINK AY, LOWER RIGHT 1
11 2703759.7 LINK AY, UPPER RIGHT 1
12 64164-19 KEY WOODRUFF.19X.75 #9 2
13 64163-67 WASHER-.516X1X12GA 4
14 521609 PULLEY, DRIVEN 10" 1
15 518438 BUSHING 2
16 521856 BEARING,BALL 2
17 521857 COLLAR,BRG LOCKING 2
18 64044-18 SCREW-SET 5/16-18 x 5/16 4
19 85010N ZERK, 1/4-28 1
20 64141-4 NUT-WLF 3/8-16 5
21 64139-24 BLT-WLF 3/8-16 X 1 4
22 64141-6 NUT, 5/16-18 8
23 548942 PULLEY, PLAIN IDLER 3.25" 1
24 548962 HOUSING,BEARING 4
25 64163-31 WSHR,.38 1.00.12 YS FLAT 4
26 64018-7 BOLT-CRG 3/8-16X1-1/4 2
27 64218-07 SCRW,.31-18 1.50 2
28 64018-9 BLT-CRG 5/16-18X3/4 4
29 64268-03 NUT-FL NYLN LOCK 3/8-16 2
30 2703101 SHAFT, LA5 JACK 1
(USED ON LA V MODELS)
2702738 SHAFT, LA4 JACK
(USED ON LA IV MODELS)
31 2703019.7 FRAME, TRANSPORT LA5 1
(USED ON LA V MODELS)
2702877.7 FRAME, TRANSPORT LA4
(USED ON LA IV MODELS)
32 4164732.2 FRAME AY, LAWNAIRE V 1
(USED ON LA V MODELS)
4164731.2 FRAME AY, LAWNAIRE IV
(USED ON LA IV MODELS)
