21
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
Lawnaire
IV & V
with EST
FIGURE 2
MAIN GROUP LAWNAIRE IV
1 64163-29 WASHER-21/64 X 1 X 11GA 5
2 64140-9 COTTER PIN, 12 x 1.12 2
3 4124192 WHEEL, 8X2.5 SEMI-PNEUM 2
4 2703148 WEIGHT, LAWNAIRE 2
5 4117195 CABLE, CLUTCH 1
6 2703444 COVER, DRIVE LA4 1
7 2703445 COVER, TINE LA4 1
8 2703611 CHAIN, #40 124P W/CONN 1
9 4113841 LINK, #40 CHAIN NICKEL 1
10 2703616.7 BRACKET AY, COVER 1
11 48228-1A CLIP-CABLE INSULATED 3
12 822474 SPACER 2
13 64140-19 PIN,COTTER 5/64 X 1/2 2
14 64139-23 BLT-WLF 3/8-16 X 1-3/4 4
15 64163-61 WSHR .81X.406X16GA A/R
16 4109880.7 LATCH, WEIGHT 2
17 4113746 SPRING, EXT .687 X 6.0 2
18 64189-20 SCREW, 1/4 -20 X 3/4 2
19 4114101 ROD, ADJUSTMENT 2
20 4114111 SPRING, TORSION 1.19 2
21 4114319 BELT, 4L-480 KEVLAR 1
22 4114608 BUSHING, SH .390 ID X .71 2
23 4115632 KNOB, 2.5" .38-24 2
24 521608 PULLEY,4 IN DIA 1
25 522516 MOUNT, ISOLATION (KC) 4
26 4118356 SPRING, EXTENSION 1
27 64188-66 PIN,CLVIS.19DIA X 1.0LG 2
28 64164-11 KEY-3/16X3/16X1-1/4 SQ 1
29 64229-01 LOCKNUT-NYLON 1/4-20 6
30 64141-6 NUT, 5/16-18 8
31 548960 SPROCKET,IDLER 2
32 64123-114 BOLT-HEX 1/4-20X1 8
33 64151-3 NUT,.38-24 HX CRWNLOCK 2
34 64188-65 PIN,CLEVIS .25 .68 PS 1
35 64163-03 WSHR-.256IDX.62ODX18GA 5
36 64268-03 NUT-FL NYLON LOCK 3/8-16 4
37 64123-47 BLT-HEX 5/16-18X1-1/4 2
38 64262-018 BLT-FLG HD 3/8-16 X 1-3/4 2
39 64262-014 BLT-FLG HD 3/8-16 X 2 2
40 64140-16 COTTER PIN-5/64X3/4 1
41 523263 BEARING - 3/4 X 1-3/8 4
42 4113972.7 COVER, CHAIN LAWNAIRE 1
