ryan 554910A - Page 25

23
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
Lawnaire
IV & V
with EST
FIGURE 3
MAIN GROUP-LAWNAIRE V
1 64163-29 WASHER-21/64 X 1 X 11GA 6
2 64140-9 COTTER PIN, 12 x 1.12 2
3 4124192 WHEEL, 8X2.5 SEMI-PNEUM 2
4 2703026 AXLE, TRANSPORT WHEEL 2
5 2703148 WEIGHT, LAWNAIRE 2
6 4117195 CABLE, CLUTCH 1
7 2703611 CHAIN, #40 124P W/CONN 1
8 4113841 LINK, #40 CHAIN NICKEL 1
9 2703616.7 BRACKET AY, COVER 1
10 2703660 COVER, SPROCKET LA5 1
11 2703661 COVER, DRIVE AND TINE 1
12 48228-1A CLIP-CABLE INSULATED 4
13 822474 SPACER 2
14 64139-23 BLT-WLF 5/16-18 X 1-3/4 4
15 64163-61 WSHR .81X.406X16GA 2
16 4109880.7 LATCH, WEIGHT 2
17 4113746 SPRING, EXT .687 X 6.0 2
18 64140-16 COTTER PIN-5/64X3/4 1
19 4114111 SPRING, TORSION 1.19 2
20 4114319 BELT, 4L-480 KEVLAR 1
21 4114608 BUSHING, SH .390 ID X .71 2
22 521608 PULLEY,4 IN DIA 1
23 522516 MOUNT, ISOLATION (KC) 6
24 4118356 SPRING, EXTENSION 1
25 64268-03 NUT-FL NYLN LOCK 3/8-16 6
26 64144-02 SNAP RING 3/4 2
27 64164-11 KEY-3/16X3/16X1-1/4 SQ 1
28 64262-011 BOLT-FLG HD 3/8-16 X 1 2
29 64141-6 NUT, 5/16-18 8
30 548960 SPROCKET,IDLER 2
31 64123-114 BOLT-HEX 1/4-20X1 10
32 523263 BEARING-3/4X1 3/8 4
33 64163-03 WSHR-.256IDX.62ODX18GA 4
34 64229-01 LOCKNUT-NYLON 1/4-20 4
35 64123-47 BLT-HEX 5/16-18X1-1/4 2
36 64262-018 BLT-FLG HD 3/8-16 X 1-3/4 2
37 64262-014 BLT-FLG HD 3/8-16 X 2 2
38 64168-4 COTTER-HAIRPIN 2
39 64188-65 PIN-CLEVIS 1/4 X .62 1
40 64189-20 SCREW, 1/4 -20 X 3/4 2
41 4113972.7 COVER, CHAIN LAWNAIRE 1
