25
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
Lawnaire
IV & V
with EST
FIGURE 4
HANDLE GROUP
1 64163-95 WSHR,.31.69.06 YS FLT 2
2 4138395 S-LA5 HANDLE W/DECALS 1
(USED ON LA V MODELS)
4138395 S-LA4 HANDLE W/DECALS
(USED ON LA IV MODELS)
3 2703060.7 HANDLE, HEIGHT ADJ. LA V 1
(USED ON LA V MODELS)
2703059.7 HANDLE, HEIGHT ADJ LA IV
(USED ON LA IV MODELS)
4 2703067.7 TUBE, CONTROL 2
5 4164738.7 BAIL AY, LA V 1
6 2703185 CNTRL AY, THROTTLE 43 1
(USED ON HONDA MODELS ONLY)
4163186 CNTRL AY, THROTTLE B&S
(USED ON B&S MODELS ONLY)
7 64123-69 BOLT-5/16-18X1-1/2 HEX 2
8 517226 BRG,SLV .33 .50 .20 4
9 518438 BUSHING.39IDX.50ODX.35 4
10 521679 BUSHING 2
11 523139 GRIP,HANDLE 2
12 4116398 BUSHING .50IDX.13 THK 4
13 64163-93 WASHER 2
14 64139-24 BLT-WLF 3/8-16 X 1 2
15 64018-7 BOLT-CRG 3/8-16X1-1/4 2
16 64018-15 BLT-CRG 5/16-18X3/4 G5 2
17 64268-02 NUT-FL NYLN LCK 5/16-18 6
18 64268-03 NUT-FL NYLN LCK 3/8-16 4
19 64262-007 BLT-FLG HD 5/16-18 X 1 2
20 64152-18 TSCRW,#8-18.50 SLF-DRL 2
(USED ON HONDA MODELS ONLY)
64197-023 SCREW-8-32 X 3/8 S-TAP
(USED ON B&S MODELS ONLY
21 822474 SPACER 2
22 830165 BUSHING 2
23 64141-2 NUT-WLF 1/4-20 2
24 64218-04 SCREW, 1/4 -20 X 3/4 1
25 78007N THROTTLE CABLE CLIP 1
(USED ON LA V MODEL ONLY)
* NOT ILLUSTRATED
