ryan 554910A - Page 29

27
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
Lawnaire
IV & V
with EST
FIGURE 5
TINE WHEEL GROUP
1 4168461 WLDMT-TINE,CENTER 1
(INCLUDES ITEMS 3,7,8 & 12)
2 4167887 SHAFT-TINE,29.5 1
(USED ON LA V MODEL ONLY)
4167881 SHAFT-TINE 22
(USED ON LA IV MODELS ONLY)
3 85010N ZERK-1/4-28 STR SF TH
(QTY 5 ON LA V)
(QTY 3 ON LA IV)
4 2703160 SPROCKET-#40 42 TOOTH 1
5 2703508 FLANGE, BEARING 2.04 ID 4
6 545786 BEARING, BALL 2
7 4167900 BEARING-1 X 1.313 X 1.063
(QTY 5 ON LA V)
(QTY 3 ON LA IV)
8 4129801 FLANGE BUSHING
(QTY 5 ON LA V)
(QTY 3 ON LA IV)
9 4168463 WLDMT-TINE,DOUBLE 2
(INCLUDES ITEMS 3,7,8 & 12)
10 64139-08 BLT-WLF 5/16-18 X 3/4 3
11 4168462 WLDMT-TINE,SINGLE-R 1
(INCLUDES ITEMS 3,7,8 & 12)
(USED ON LA V MODELS ONLY)
12 4167899 SEAL-1.0 X 1.312 X 0.125
(QTY 5 ON LA V)
(QTY 3 ON LA IV)
13 4168460 WLDMT-TINE,SINGLE-L 1
(INCLUDES ITEMS 3,7,8 & 12)
(USED ON LA V MODELS ONLY)
14 64163-64 WASHER-.531 x 2.00 x .125
(QTY 8 ON LA V)
(QTY 4 ON LA IV)
15 4167879 MOUNT-SPROCKET 1
16 522361 TINE, CORING 3/4
(QTY 42 ON LA V)
(QTY 30 ON LA IV)
17 64018-34 BLT-CAR 5/16-18 X 1-1/2
(QTY 84 ON LA V)
(QTY 60 ON LA IV)
18 64151-15 NUT-HEX 5/16-18 CTRLCK
(QTY 84 ON LA V)
(QTY 60 ON LA IV)
19 64018-9 BLT-CRG 5/16-18X3/4 G5 4
20 64141-6 NUT-WLF 5/16-18 4
21 64044-2 SET SCREW-5/16-18X3/8 2
22 521854 LOCK COLLAR 2
