29
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
Lawnaire
IV & V
with EST
FIGURE 6
DRUM GROUP
1 2702741.7 PLATE, FLANGE 1
2 2703108.7 DRIVE AY, LA5 DRUM 1
(USED ON LA V MODELS)
2703102.7 DRIVE AY, LA4 DRUM
(USED ON LA IV MODELS)
3 2703157 SPROCKET, 30T .50P 1
4 2703508 FLANGE, BEARING 2.04 I.D. 4
5 2703785 DRUM, WATER LA5 1
(USED ON LA V MODELS)
2703783 DRUM, WATER LA4
(USED ON LA IV MODELS)
6 522480 GASKET, 4.50 DIA. 1
7 522481 GASKET, 3.00 DIA. 1
8 545786 BEARING ASSEMBLY 2
9 545887 RING AY, SPLIT 2
10 64139-08 BOLT-5/16-18X3/4 WLF 3
11 64141-6 NUT, 5/16-18 7
12 64018-9 BLT-CRG 5/16-18X3/4 G5 4
13 821274 PLUG, DRAIN 1
14 64025-02 NUT-HEX 5/16-18 12
