Ryobi AP1301 Repair Sheet

RYOBI 13 in. PLANER – MODEL NUMBER AP1301
3
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your PLANER or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 089170101800 HANDLE ASSEMBLY (INC. KEY NOS. 2-6 AND 91) ...................... 1
2 089170101001 HANDLE KNOB ASSEMBLY .......................................................... 1
3 089170101002 HANDLE ARM ASSEMBLY ............................................................ 1
4 089170101003 * SCREW (M5 X P0.8 X 20 mm
HEX SOC.) ..................................... 1
5 089170101008 * SCREW (M4 X P0.7 X 12 mm HEX SOC.) ..................................... 1
6 089170101010 * WASHER (Ø4.3 X Ø12 X 1t) ........................................................... 1
7 089170101011 CONNECTION TUBE - SHORT (OD.20 X 1.0t X 225 mm) ............. 2
8 089170101012 CONNECTION TUBE - LONG (OD.20 X 1.0t X 485 mm) ............... 2
9 089170101013 * SCREW (M6 X P1 X 60 mm SOC. BUTTON HD.) .......................... 4
10 089170101014 * SCREW (M5 X P0.8 X 8 mm PAN HD.) .......................................... 3
11 089170101015 DUST CHUTE PLATE ..................................................................... 1
12 089170101016 * SCREW W/WASHER (M5 X P0.8 X 10 mm) ................................... 1
13 827767 CORD CLAMP ................................................................................ 1
14 821065-2 SET SCREW (M5 X P0.8 X 8 mm) .................................................. 1
15 089170101019 * SCREW (M5 X P0.8 X 8 mm PAN HD.) .......................................... 2
16 813314-8 LOCK WASHER (M5) ..................................................................... 2
17 817453 RETAINING RING ........................................................................... 3
18 827794 CHAIN ............................................................................................ 2
19 827772 SPROCKET .................................................................................... 4
20 827773 SPACER ......................................................................................... 1
21 828943-4 * SCREW (M5 X P0.8 X 35 mm HEX SOC.) ...................................... 4
22 089170101801 GEARBOX ASSEMBLY .................................................................. 1
23 089170101038 GEAR BOX COVER ........................................................................ 1
24 827784 PINION .......................................................................................... 1
25 820722-5 BALL BEARING (6203ZZ) .............................................................. 2
26 089170101900 WARNING LABEL (DUST CHUTE-1) .............................................. 1
27 089170101907 WARNING LABEL (DUST CHUTE-2) .............................................. 1
28 089170101908 WARNING LABEL (DUST CHUTE-3) .............................................. 1
29 089170101041 CHUTE DUST (INC. KEY NOS. 26-28) ........................................... 1
30 089170101042 HOOD DOOR ................................................................................. 1
31 089170101043 HURRICANE KNOB ....................................................................... 2
32 089170101044 * SCREW (M5 X P0.8 X 10 mm PAN HD.) ........................................ 4
33 089170101045 * SCREW (M5 X P0.8 X 10 mm HEX HD.) ........................................ 2
34 089170101046 * WASHER (Ø5.2 X Ø16 X 1.5t) ........................................................ 4
35 827680 CUTTER HEAD ............................................................................... 1
36 089170101137 * SCREW (M5 X P0.8 X 10 mm HEX SOC.) ...................................... 1
37 089170101047 * SCREW W/WASHER (M4 X P0.7 X 10 mm) ................................... 2
38 089170101048 BELT GUARD ................................................................................. 1
39 828788 PLUNGER ...................................................................................... 1
40 827738 SPRING COIL ................................................................................. 1
41 089170101051 ELEVATION NUT (14 mm) .............................................................. 4
42 089170101052 UPPER FRAME .............................................................................. 1
43 821065-1 * SCREW (M5 X P0.8 X 5 mm) .......................................................... 4
44 089170101054 CUTTER HEAD LOCK ................................................................... 1
45 827737 SPACER ......................................................................................... 1
46 828027 * SCREW (M5 X P0.8 X 12 mm HEX SOC.) ...................................... 1
47 821063 * WASHER (Ø8 X Ø18 X 2t) .............................................................. 1
