Ryobi AP1301 Repair Sheet

RYOBI 13 in. PLANER – MODEL NUMBER AP1301
4
48 089170101058 * SCREW (M8 X P1.25 X 20 mm HEX HD.) ...................................... 1
49 827711 BLADE LOCKING PLATE .............................................................. 2
50 089170101062 PLANER BLADE (19 X 1.8 X 344) ................................................... 2
51 828791 SCREW ........................................................................................ 14
52 818654-9 KEY (5 X 12 mm) ............................................................................ 1
53 827786 BEARING RETAINER .................................................................... 1
54 820379 * SCREW (M5 X P0.8 X 12 mm HEX SOC.) .................................... 14
55 089170101069 PULLEY CUTTER HEAD ............................................................... 1
56 827793 BELT DRIVE (135J6) ....................................................................... 1
57 827788 NUT HEX (M16LH X 8t) .................................................................. 8
58 089170101072 SMALL COVER (RIGHT SIDE) ........................................................ 1
59 089170101073 DEPTH INDICATOR ....................................................................... 1
60 089170101074 * SCREW W/WASHER (M4 X P0.7 X 8 mm) ..................................... 1
61 827789 PULLEY MOTOR ............................................................................ 1
62 089170101901 ZERO RESET DIAL LABEL ............................................................. 1
63 089170101076 ZERO RESET DIAL ......................................................................... 1
64 089170101077 LARGE COVER (RIGHT SIDE) ........................................................ 1
65 089170101902 SCALE LENGTH ............................................................................. 1
66 089170101903 LOGO LABEL ................................................................................. 1
67 089170101802 MOTOR/SWITCH ASSEMBLY (INC. KEY NOS. 66 AND 95) ......... 1
68 089170101078 SMALL COVER (LEFT SIDE) .......................................................... 1
69 089170101079 LARGE COVER (LEFT SIDE) .......................................................... 1
70 827758 SPRING COIL - LEFT ..................................................................... 2
71 AP13084 RETAINER PLATE .......................................................................... 4
72 827765 * WASHER (Ø5.5 X Ø19 X 2t) ........................................................... 1
73 828939 ROLLER INFEED ........................................................................... 1
74 828938 ROLLER OUTFEED ....................................................................... 1
75 827755 SPRING COIL - RIGHT ................................................................... 2
76 AP13089 BEARING BLOCK (23 mm) ............................................................ 4
77 089170101087 R.H. SPINDLE ................................................................................ 1
78 089170101088 BASE .............................................................................................. 1
79 089170101089 L.H. SPINDLE ................................................................................. 1
80 089170101803 POST .............................................................................................. 4
81 827705 RAIL GUIDE .................................................................................... 2
82 089170101094 WEAR PLATE ................................................................................. 1
83 089170101095 * SCREW (M10 X P1.5 X 40 mm HEX) .............................................. 4
84 089170101096 BALL BEARING (6000ZZ) .............................................................. 2
85 089170101097 SPROCKET .................................................................................... 2
86 089170101098 * WASHER (Ø4 X Ø15 X 2t) .............................................................. 2
87 089170101099 * SCREW (M4 X P0.7 X 12 mm HEX SOC. HD.) ............................... 2
88 089170101100 CHAIN ............................................................................................ 1
89 089170101904 SIDE COVER LABEL ...................................................................... 2
90 089170101101 * WASHER (Ø10.5 X Ø21 X 2t) ......................................................... 4
91 089170101007 WASHER ........................................................................................ 1
92 827756 WRENCH (M8 X M10) .................................................................... 1
93 827757 HEX KEY (M4 X 120 mm) ............................................................... 1
94 089170101103 BLADE WRENCH ........................................................................... 1
95 089170101906 MOTOR WARNING LABEL ............................................................ 1
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your PLANER or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY.

Ryobi AP1301 Specifications

General

Brand	Ryobi
Model	AP1301
Category	Planer
Language	English
