PHILLIPS
SCREWDRIVER
FRAMING SQUARE
WRENCH (2)
1/2 in., 8 mm
Fig. 4
TOOLS NEEDED
The following tools (not included) are needed for making adjustments:
Fig. 5
Rip Fence ......................................................................1
Miter Gauge ....................................................................1
Blade Guard Assembly ...................................................
1
Wheel..............................................................................2
Washer ...........................................................................
2
Shoulder Bolt ..................................................................2
LOOSE PARTS LIST
Large Wrench .................................................................1
Small Wrench .................................................................
1
Bumper ...........................................................................2
Screw .............................................................................
4
Operator's Manual (Not Shown)
COMBINATION
SQUARE
HEX KEY,
4 mm
To Next Page
