LOOSE PARTS

Fig. 4

The following items are included with the drill press:

Head Assembly .................................................................1

Column Assembly .............................................................1

Table Assembly .................................................................1

Base ..................................................................................1

Hex Key (3 mm, 4 mm, and 5 mm)....................................3

Hex Bolts (M8)...................................................................4

Feed Handles ....................................................................3

Table Adjustment Handle ..................................................1

Table Lock Handle.............................................................1

AA Batteries.......................................................................2

Chuck ................................................................................1

Chuck Key .........................................................................1

Vise....................................................................................1

Worm Gear ........................................................................1

Operator’s Manual (not shown) .........................................1

COLUMN

ASSEMBLY

TABLE ASSEMBLY

BASE

HEX KEY

HEX BOLTS

TABLE LOCK

HANDLE

FEED HANDLES

AA BATTERIES

HEAD

ASSEMBLY

TABLE

ADJUSTMENT

HANDLE

CHUCK

KEY

VISE

CHUCK

WORM

GEAR
